Memory device is serial eeprom Seiko S29190 SMD8 package.
Eeprom can be located in 2 different positions.
The expected file size is 128 bytes.
Use JMA TPX2 – Errebi TX2 or CN2/CN5 or K-JMD or YS-01 transponder.
The written transponder is ready and programmed to start the bike.
Note: The latest Yamaha immobox Moric does NOT HAVE serial eeprom, so please check your immobox before purchasing this software. If there is no serial eeprom, but a 16-pin chip TMS3705 you need software module 108.
Vehicles equipped with this unit:
Yamaha: BT1100, FJR, FZR, FZ1, FZ6, FZS, XT, XTR, XTX, XVX, YZF
MBK: Skycruiser 125
