KYDZ Stone Hand Held Key Tool Programmer for Android Version

KYDZ Smart Car Remote Key Programmer Chip Generation Identification Copy Smart Card Frequency Test

KYDZ Smart Key Programmer Parameter:

• Size: 5.0 inch
• Battery: 5000mAh/3.7V
• Charging: DC 5V/1A
• Using environment: -10°C---55°C

Supported Languages: English and Chinese

What are the new things at KYDZ Key Programmer on 2020 Upgrade?

• Generating New Cadillac Series Smart Card
• Generating New Buick Series Smart Card
• Generating Chevrolet Series Smart Card
• Generating 08 Accord, Crosstour, Spirior (Modified Crosstour can't find key tips)
• Supplement Great Wall H6 Smart Card
• Generating Zhidou Smart Card
• Generating Vision X6 Smart Card

KYDZ Smart Key Programmer Functions:

• Chip Identification, Copy, and Generation
• Anti-theft Data write Key
• Remote Generation
• Support Frequency Detection, Infrared Detection
• NXP Renew
• Smart Card Generation

Power On and Off statuses:

1. Power On press the battery button in 3 to 5 seconds, enter the Android screen, then click "agree".
2. Power Off press the battery button in 2 to 3 seconds, appearing the word "power off", then click the "power off".

KYDZ Smart Key Programmer Main Menu:

1. Active message showing: show the new message of KYDZ
2. Remote making: producing the RKE remote key.
3. Detecting the frequency and infrared.
4. NXP renews OEM and after-market is supported.
5. Chip identify: recognize the chip, edit, and read the EEPROM.
6. Copy:(still researching and developing).
7. Special function:(still research and develop).
8. Smart card: producing all kinds of PKE remote keys.
9. Making chip:G make,G mass,ID67,ID68,ID70,ID70E,ID33,ID40,ID4, ID42,ID43,ID44,ID45,ID46,ID60,ID61,ID62,ID63 and so on.
10. Setting: wifi setting, display setting, volume setting, language setting, PC mode.

How to use KYDZ Smart Key Programmer:

Remote Making :

Please check if the battery of the RKE remote key can work before making it, then clicking the "remote make"
Then choose the area then choose the type of car then enter the screen of the remote makes
Then put the RKE remote key into the Key slot then appear the word "connect the remote key"
Then click generate Then remote making then read successfully then confirm.

Detecting Frequency

- Detecting Frequency: click "frequency" then put the remote key near this machine then press the button of the remote key
Then appears relative information of the key.
- Detecting Infrared: click "frequency" then put the remote key near this machine then press the button of the remote key to the appearing information.

NXP Renew

Click "NXP Renew" then choose the area then choose the type of the car then enter the screen and connect the circuit then use the PS2 wire to connect the port of the PS2
Then click "refresh/update" Then Then reading the chip then -read successfully then click "Confirm"

Chip Identity

(1) Click "chip identity" then put the chip into the Key slot then click chip identifies then recognizing then finished then show the information of the chip click "chip edit"
(2) Click "chip identity" then out the chip into the key slot -click "EEPROM" then click "read the data of EEPROM"

Copy:(still researching and developing).

Special function:(still research and develop).

Smart Card

Please check if the battery of the RKE remote key can work before making, then clicking the "remote make" then choose the area then choose the type of car then enter the screen of remote make Then read PKE remote key Then adjust it until it displays the "PKE remote key" then click "generate" Then confirm

Making Chip

Car Model: put the chip into the key slot then click "make chip" then car model then choose the area then choose the type of the car
Then click "Importing files" Then confirm then back to the last interface Then click "generate" Then confirm
Image generator: put the chip into the key slot then click "make chip" Then click "image generator" Then choose G producing as your need.
Unlock: put the chip into the key slot then click "make chip" then click "unlock" then choose the area then the type of the car Then detect the battery Then detect the data of the factory then reset the chip.

9. Setting

1. WIFI Setting: click "setting" Then click "wifi setting" then choose the internet then -connect
2. Display Setting: click "setting" Then click "display setting" then adjust the light of the screen as you want
3. Volume Set: click "setting" Then click "volume setting" then adjust the volume of the screen as you want
4. Language Setting: click "setting" Then English/Chinese
5. PC Mode: connect to the computer
6. About: showing the version of this machine

KYDZ Smart Key Programmer Package includes:

• 1pc x KYDZ Key programmer
• 2pcs x Cable
• 2pcs x KYDZ Remote(no chip)
• 1pc x User Guide
