- Serial Number Is Required .
- After receiving the payment notification and Serial Number, we will promptly send you the file or an update notification.
Models
Memory device is serial eeprom 95c160 or 92c320 SSOP8 package.
The expected file size is 2048 or 4096 bytes.
Use PCF7936 or Silca T14 – JMA TP12 or CN3 transponder or remote key.
IMPORTANT when you want to program the remote key: open the key and look on PCB.
You will find 2 SMD chips – PCF7946 (SMD 14 pins) and a smaller SMD chip, which can be with 8, 10, or 16 pins.
If a smaller SMD chip is with 10 or 16 pins, PROGRAM KEY AS TYPE 1.
If a smaller SMD chip is with 8 pins, PROGRAM KEY AS TYPE 2.
IMPORTANT: if the buttons of the remote operate, but do not work properly, for ex. button for locking opens the trunk, this is NOT A TMPro SOFTWARE PROBLEM. Use another type of remote.
The software shows a 5-digit PIN code.
The written transponder is ready and programmed to start the vehicle.
Vehicles equipped with this unit:
Fiat: Bravo(2007-), Ducato(2006-), Stilo(2007-), Punto(2007-), Idea(2008-)
Citroen: Jumper(2006-), Relay(2006-)
Peugeot: Boxer(2006-)
Dodge: Promaster(2011-)
Lancia: Ypsilon(2007-), Musa(2007-)
