Tmpro 2 Tmpro 2 Software module 118 – Alfa Romeo, Fiat key reader TEG

Memory device is serial eeprom 24c04 SMD8 package.
The expected file size is 512 bytes.
The software shows a 5-digit PIN code.
Use PCF7936 or Silca T14 – JMA TP12 or CN3 transponder or remote key with PCF7941.
The written transponder or remote key is ready and programmed to start the car.
The Remote is also ready to operate, no need for OBD2 programming.
NOTE 1:Remote part will work 100% ONLY if the key is unlocked with TMPro! If your key is unlocked, but you don`t know if it was unlocked using TMPro – unlock it with TMPro again, and view the connection diagram.
NOTE 2 Your key can be 2 different types – with PCF7341 and with PCF7941. At reading of key TMPro will show PCF7941 for both types. Click here to determine the correct type of PCF in your key.
NOTE 3:Software supports also a file reading from Motorola in BSI, but in this case, you must program the key by OBD2 to start the car and activate remote. BSI can be read by OBD2 ONLY when there is a valid key i.e. job is “Make Spare key”. If ALL KEYS ARE LOST you must remove BSI and read Motorola by test points, view the connection diagram.
Vehicles equipped with this unit:
Alfa Romeo: 159, Brera, Spider
Fiat: Croma
