The memory device is the Texas Instrument MCU TMS370C702 PLCC28 package or Motorola MCU HC908AB16A QFP64 package.
Motorola is locked, the password for the reading eeprom area is F3-B1-F3-AB-F3-A5-F3-9F.
The expected file size is 256 bytes.
The software shows the PIN code.
Use PCF7935 or Silca T15 – JMA TP14 transponder.
The written transponder is ready and programmed to start the vehicle.
Vehicles equipped with this unit:
Opel: Agila, Astra G, Combo C, Corsa C, Meriva, Omega(1999-), Sintra(1999-), Tigra, Vectra B(1999-), Zafira
Fiat: Sedici
Suzuki: SX4
