Xtool KS-1 Toyota Smart Key Emulator Support 94 / D4 98 39 88 / A8 A9

Xtool KS-1 Toyota Smart Key Simulator

Fit for PS90 X100 PAD2 PAD3 PAD Elite A80 H6 All Lost via OBD2 KC100

KS-1 is a 5-1 simulation card that can eliminate the need to disassemble the smart box and other modules.
As long as the original car data is read from the OBD to generate the simulation card.
The ignition switch can be turned on to achieve the function of scanning and adding the smart key.

Xtool KS1 Smart Key Toyota Functions

More Cars	Support Toyota 94 / D4, 98, 39, 88 / A8, A9 smart keys all lost fast matching	All lost No disassembly	Read the original car data from OBD to generate an emergency simulation key, and directly drive the car without disassembly
Intelligently Generate New Keys	Through the reading of the original car data, a smart key is generated	Reuse	Turn off the power or remove the battery, and you can restore it to its initial state

Xtool KS-1 Key Toyota Smart Parameters

standby current	≤2ua	Operating Current	≤8ma	Dimensions	66*40*12mm
Working Temperature	-10℃~60℃	Storage Temperature	-20℃~70℃	Battery	CR2025 3V 165mAh
Reading and writing frequency	125kHz	Status indicator lamp	1pc (mode: turn on and light up for 2s and then extinguish; Flicker, flash, 0.5s/ time when writing or reading)	Update	The simulation card firmware can be updated with KC100

Xtool KS1 Smart Key Toyota Key Type-Tested

vehicle	Year	Key type	Support or not	Remarks
RAV4	2015	88	Yes
Alphard	2013	94	Yes
Alphard	2015	A9	Yes
Previa	2008	94	Yes
Crown	2010	98	Yes
Crown	2015	A8	Yes
Crown	2016	A8	No	After 2016, Toyota Crown is not supported TANGO, K518 even rival products are not supported
Prado	2011	98	Yes
Previa	2013	94	Yes
Reiz	2011	98	Yes
Innova		39	Yes	The car is being tested for the Indian Tango
